Plan Specification: HHF-2777

Total Entire Building: 1,285

Total Living Per Unit: 1,285

Main Level: 624

Second Level: 661

Bedrooms: 3

Baths: 2        Half: 1

Garages: 2

Width: 21 ft Depth: 36 ft

Foundation: Slab Foundation-Included


Pricing Options Click here...

Main Plan Photo
© copyright by designer

Plan: HHF-2777

Plan this charming duplex for sloping lots - the double garage tucks into the hillside and the living space sits above. Reach the main floor via a staircase in the garage or from street-level at the lovely covered porch. The living room has a nine-foot ceiling, corner fireplace, box-bay window and built-in media center. The dining room is also graced by a nine-foot ceiling and has two box-bay windows. The kitchen includes an island and a pantry. Three bedrooms and a laundry alcove are found upstairs. Bedrooms 2 and 3 have the use of a full bath with a hall linen closet. The master salon is vaulted and has a walk-in closet and full bath.

ShareThis
$50 off any House Plan through midnight tonight! see details
Additional Images

Plan Pricing Packages
HOUSE PLAN SETS

 Basic Package    $1,000.00
 Construction Package    $1,100.00
 Modification Package: PDF    $1,495.00
 Modification Package: CAD    $2,300.00
FOUNDATION OPTIONS

 Slab Foundation-Included  $0.00
ADDITIONAL PLAN OPTIONS

 Additional Sets  $40.00
 Full Reverse Sets  $100.00
PROMOTIONAL ITEMS

 Custom Adult T-shirt  $25.00
Size:
Color:
Best Price Guarantee, learn more
For more details about our plan packages click here



Email Us   Call Us   Live Chat

Key Features
  • Attached
  • Country Kitchen
  • Covered Front Porch
  • Fireplace
  • Foyer
  • Front Porch
  • Great Room
  • Kitchen Island
  • Laundry 2nd Fl
  • Master Bdrm Upstairs
  • Rear-entry
  • Slab
  • Walk-in Closet
  • Walk-in Pantry
Need to make changes?
Call for a free modification quote
877-895-5299
or use this quote form
Architect's Preferred Products:
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments
10% off ALL online house plan packages! Promo Code: Thanks2011

© copyright by designer
First Floor Plan:





© copyright by designer
Second Floor Plan:


© copyright by designer
Lower Floor Plan:

Top

Plan Details

General House Information
Number of Stories:2
Width:21' 0"
Depth:36' 0"
Dwelling Number:Duplex
Bonus Access:None

Exterior Style
  • Traditional
  • Country
  • Craftsman
  • PDFs Fast!

Number of Rooms
Bedrooms:3
Full Baths:2
Half Baths:1

Finished Square Footage
Main Level:624 Sq. Ft.
Upper Level: 661 Sq. Ft.
Total: 1285 Sq. Ft.

Unfinished Square Footage
Garage:603 Sq. Ft.
Porch:97 Sq. Ft.

Garage
Garage Type:Attached
Garage Size:2


Foundation
  • Slab Foundation-Included

House And Ceiling Heights
First Floor Ceiling:9
Second Floor Ceiling:8
Maximum House Height:28' 0"

Framing Information
Roof Framing:Truss
Exterior Wall Framing:2x6

Roof Pitch
Primary:8/12

Roof Load
Live:25
Dead:15
Wind:0

INSULATION
Exterior Wall:21
Interior Wall:0
Ceiling:38
Floor:30

Number of Rooms
Bedrooms:3
Full Baths:2
Half Baths:1
