Plan: 2802

Pin It
Similar plans: 3802, 1583, 2799
More plans by this designer/architect
ShareThis
Purchase Plans
© copyright by designer
First Floor Plan:

Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor Plan:

Plan Specification
Total Square Footage: 2,245
Main Level: 1,720
Second Level: 525
Bonus: 224
Bedrooms: 3
Baths: 2 Half: 1
Garages: 2
Width/Depth: 68 ft / 57 ft
Foundation: Basement, Crawl Space, ICF - Basement (Insul. Conc. Forms), ICF - Slab (Insul. Conc Forms), Slab Foundation
ENERGY STAR APPROVED
Get Your House Plans In Minutes!
NEW PDFs Now! Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
House Plan Pricing
$179.00
PDFs Now! $675.00
$716.00
$775.00
$895.00
PDFs Now! $995.00
$1,025.00
$1,545.00
More details about our plan packages
Foundation Options
PDFs Now! available $0.00
PDFs Now! available $0.00
$100.00
PDFs Now! available $150.00
$175.00
Additional Plan Options
$0.00
$75.00
$50.00
$50.00
$350.00
$250.00
$150.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
• Attached
• Covered Front Porch
• Covered Rear Porch
• Expandable
• Fireplace
• Great Room
• Laundry 1st Fl
• Master Bdrm Main Floor
• Nook / Breakfast Area
• Rear Porch
• Vaulted Ceilings
• Wrap Around Porches
• Wraparound Porch
Plan Details
General House Information
2
Number of Stories:
68' 0"
Width:
57' 6"
Depth:
Single
Dwelling Number:
2nd Floor
Bonus Access:
Exterior Style
Traditional
Country
Southern
Farm House
Concrete
Tennessee
North Carolina
Number of Rooms
3
Bedrooms:
2
Full Baths:
1
Half Baths:
Finished Square Footage
1,720 Sq. Ft.
Main Level:
525 Sq. Ft.
Upper Level:
2,245 Sq. Ft.
Total:
Unfinished Square Footage
502 Sq. Ft.
Garage:
224 Sq. Ft.
Bonus Room:
GARAGE
Side
Garage Location:
2
Garage Size:
Foundation
Basement
Crawl Space
ICF - Basement (Insul. Conc. Forms)
ICF - Slab (Insul. Conc Forms)
Slab Foundation
House And Ceiling Heights
9.1
First Floor Ceiling:
25' 0"
Maximum House Height:
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
9: 12
Primary:
Roof Load
30
Live:
10
Dead:
Insulation (R)
13
Exterior Wall:
0
Interior Wall:
30
Ceiling:
19
Floor:
Number of Rooms
3
Bedrooms:
2
Full Baths:
1
Half Baths:
Architect's Preferred Products
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments
