Plan Specification: HHF-3572

Total Square Footage: 1,868

Main Level: 1,868

Bedrooms: 3

Baths: 2

Garages: 2

Width: 62 ft Depth: 64 ft

Foundation: Concrete Slab Foundation, Optional Crawl Space Foundation, Optional Custom Foundation Design


Pricing Options Click here...

Main Plan Photo
© copyright by designer

Plan: HHF-3572

A U-shaped kitchen services the dining room and its own eating area. It also boasts a built-in desk, a handy pantry closet and access to the nearby laundry room and carport. The wide master bedroom hosts a lavish master bath with a spa tub, a separate shower and his-and-hers dressing areas. Across the home, the two secondary bedrooms share another full bath. This is a super energy saving design.

ShareThis
SITE-WIDE SALE! 10% off all modifications or 10% off any plan package over $500 see details
Additional Images


Get Your House Plans In Minutes!

NEW PDFs Now! Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
Plan Pricing Packages
HOUSE PLAN SETS

 PDF BID SET   PDFs Now!   $660.00
 1 set    $664.00
 4 sets    $684.00
 8 sets    $729.00
 12 sets    $779.00
 Reproducible Set    $819.00
 PDF Construction Set - 1 Build   PDFs Now!   $819.00
 Cad Files    $1,638.00
FOUNDATION OPTIONS

 Concrete Slab Foundation PDFs Now! available   $0.00
 Optional Crawl Space Foundation PDFs Now! available   $90.00
 Optional Custom Foundation Design  $300.00
ADDITIONAL PLAN OPTIONS

 Additional Sets  $50.00
 Materials List PDFs Now! available   $75.00
 Materials List (additional sets are available)  $15.00
 Mirror Reverse Set  $60.00
PROMOTIONAL ITEMS

 Custom Adult T-shirt  $25.00
Size:
Color:
Best Price Guarantee, learn more
For more details about our plan packages click here



Email Us   Call Us   Live Chat

Key Features
  • Attached
  • Covered Front Porch
  • Front Porch
  • Laundry 1st Fl
  • Master Bdrm Main Floor
Need to make changes?
Call for a free modification quote
877-895-5299
or use this quote form

© copyright by designer
First Floor Plan:




Top

Plan Details

General House Information
Number of Stories:1
Width:62' 0"
Depth:64' 0"
Dwelling Number:Single
Bonus Access:None

Exterior Style
  • Traditional
  • Colonial
  • Southern
  • European

Facade
  • Brick

Number of Rooms
Bedrooms:3
Full Baths:2

Finished Square Footage
Main Level:1868 Sq. Ft.
Total: 1868 Sq. Ft.

Unfinished Square Footage
Garage:691 Sq. Ft.

Garage
Garage Type:Attached
Garage Size:2


Foundation
  • Concrete Slab Foundation
  • Optional Crawl Space Foundation
  • Optional Custom Foundation Design

Framing Information
Roof Framing:Stick
Exterior Wall Framing:2x6

Roof Pitch
Primary:7/12

Roof Load
Live:20
Dead:10

INSULATION
Exterior Wall:19
Interior Wall:0
Ceiling:38
Floor:19

Number of Rooms
Bedrooms:3
Full Baths:2
