Plan Specification: HHF-3813

Total Square Footage: 1,438

ENERGY STAR

Main Level: 988

Second Level: 450

Bedrooms: 4

Baths: 2

Garages: 1

Width: 54 ft Depth: 40 ft

Foundation: Basement, Crawl Space, Slab Foundation


Pricing Options Click here...

Main Plan Photo
© copyright by designer

Plan: HHF-3813

Although it looks like an A-frame, this dramatic home is really a conventionally framed 1-1/2 story with a very steep roof line. The roof is an ideal place for solar collecting panels, but the home can be built with conventional heating. The interior is dramatic and it includes a huge vaulted great room.

ShareThis
Additional Images


Get Your House Plans In Minutes!

NEW PDFs Now! Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
Plan Pricing Packages
HOUSE PLAN SETS

 PDF BID SET   PDFs Now!   $525.00
 Four Set Package    $605.00
 Eight Set Package    $685.00
 PDF Construction Set - Single Use   PDFs Now!   $785.00
 Reproducible Vellum Set    $810.00
FOUNDATION OPTIONS

 Crawl Space PDFs Now! available   $0.00
 Slab Foundation PDFs Now! available   $0.00
 Basement PDFs Now! available   $100.00
ADDITIONAL PLAN OPTIONS

 ENERGY STAR® Plan Package  $275.00
 Multiple Use License (For more than one home)  $250.00
 Additional Set  $50.00
 Material List (if available)  $75.00
 Mirror Reverse  $50.00
 High Wind Structural Drawings  $150.00
PROMOTIONAL ITEMS

 Custom Adult T-shirt  $25.00
Size:
Color:
Best Price Guarantee, learn more
For more details about our plan packages click here



Email Us   Call Us   Live Chat

Key Features
  • Attached
  • Fireplace
  • Great Room
  • Master Bdrm Main Floor
  • Rear Porch
  • Screened Porch/Sunroom
  • Storage Space
  • Vaulted Ceilings
Need to make changes?
Call for a free modification quote
877-895-5299
or use this quote form
Architect's Preferred Products:
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments

© copyright by designer
First Floor Plan:





© copyright by designer
Second Floor Plan:

Top

Plan Details

General House Information
Number of Stories:1.5
Width:54' 4"
Depth:40' 9"
Dwelling Number:Single

Exterior Style
  • Contemporary
  • Beach
  • Vacation
  • Modern
  • Mountain

Facade
  • Owner's Choice
  • OwnersChoice
  • OwnersChoice

Number of Rooms
Bedrooms:4
Full Baths:2

Finished Square Footage
Main Level:988 Sq. Ft.
Upper Level: 450 Sq. Ft.
Total: 1438 Sq. Ft.

Unfinished Square Footage
Garage:288 Sq. Ft.
Deck:778 Sq. Ft.

Garage
Garage Type:Attached
Garage Size:1


Foundation
  • Basement
  • Crawl Space
  • Slab Foundation

House And Ceiling Heights
First Floor Ceiling:8'-1"
Second Floor Ceiling:8'-1"
Maximum House Height:26' 0"

Framing Information
Roof Framing:Stick
Exterior Wall Framing:2x4

Roof Pitch
Primary:14/ 12
Secondary:7/ 12

Roof Load
Live:30
Dead:10

INSULATION
Exterior Wall:13
Interior Wall:0
Ceiling:30
Floor:19

Number of Rooms
Bedrooms:4
Full Baths:2
