Plan Specification: HHF-4739

Total Square Footage: 1,548

Main Level: 1,288

Second Level: 260

Bedrooms: 2

Baths: 2

Garages: 2

Width: 64 ft Depth: 36 ft

Foundation: Concrete Slab Foundation, Optional Crawl Space Foundation, Optional Custom Foundation Design


Pricing Options Click here...

Main Plan Photo
© copyright by designer

Plan: HHF-4739

Perfect for lake or river sites, the open design of this 2-bedroom cottage offers a rear view from all rooms. Each bedroom has abundant closet space and private bath access. The living room features include a massive wood burning corner fireplace and sloped ceilings. All bedrooms and the living room open to the rear patio via French doors. A spiral staircase accesses an upper level balcony and the open design of the gallery allows for an overlooking view of both the living and dining areas. A built-in wet bar provides the finishing touch for an evening of entertaining. For the man, there is even a built-in workbench in the garage. This is a super energy saving design with 2x6 exterior walls.

ShareThis
Additional Images


Get Your House Plans In Minutes!

NEW PDFs Now! Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
Plan Pricing Packages
HOUSE PLAN SETS

 PDF BID SET   PDFs Now!   $570.00
 1 set    $574.00
 4 sets    $594.00
 8 sets    $654.00
 12 sets    $704.00
 Reproducible Set    $754.00
 PDF Construction Set - 1 Build   PDFs Now!   $754.00
 Cad Files    $1,508.00
FOUNDATION OPTIONS

 Concrete Slab Foundation PDFs Now! available   $0.00
 Optional Crawl Space Foundation PDFs Now! available   $90.00
 Optional Custom Foundation Design  $300.00
ADDITIONAL PLAN OPTIONS

 Additional Sets  $50.00
 Materials List PDFs Now! available   $70.00
 Materials List (additional sets are available)  $15.00
 Mirror Reverse Set  $60.00
PROMOTIONAL ITEMS

 Custom Adult T-shirt  $25.00
Size:
Color:
Best Price Guarantee, learn more
For more details about our plan packages click here



Email Us   Call Us   Live Chat

Key Features
  • Attached
  • Crawlspace
  • Side-entry
  • Slab
  • Vaulted Ceilings
  • Vaulted Dining Room
  • Vaulted Living Room
Need to make changes?
Call for a free modification quote
877-895-5299
or use this quote form
Architect's Preferred Products:
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments

© copyright by designer
First Floor Plan:





© copyright by designer
Second Floor Plan:

Top

Plan Details

General House Information
Number of Stories:1.5
Width:64' 0"
Depth:36' 0"
Dwelling Number:Single
Bonus Access:None

Exterior Style
  • Modern
  • Mountain
  • Vacation
  • Contemporary

Number of Rooms
Bedrooms:2
Full Baths:2

Finished Square Footage
Main Level:1288 Sq. Ft.
Upper Level: 260 Sq. Ft.
Total: 1548 Sq. Ft.

Garage
Garage Type:Attached
Garage Size:2


Foundation
  • Concrete Slab Foundation
  • Optional Crawl Space Foundation
  • Optional Custom Foundation Design

House And Ceiling Heights
First Floor Ceiling:8
Maximum House Height:0' 0"

Framing Information
Exterior Wall Framing:2x6

Roof Pitch
Primary:8/12

INSULATION
  • Per IRC Climate Zones

Number of Rooms
Bedrooms:2
Full Baths:2
