Plan: 4924

This stunning estate home plan with five bedrooms will make you feel like you've been whisked away to another place and time. Repeated arches give the facade a Spanish, Tuscan or Mediterranean feel. A fireplace warms the living room, at the center of the floor plan. Treat your visitors to a feast in the dining room, a tournament in the billiard room, and a good night's sleep in the guest room. A bayed den could serve as a bedroom. The family chef will certainly approve of the kitchen's sensible layout. The family room is a beautiful spot for quiet relaxation. The covered rear patio is nothing short of fantastic, with its pool bath, summer kitchen and gazebo. Back in the living room, a curved staircase ascends to the upper floor, where you will find the awesome master suite with just about every amenity you could imagine. An exercise room and two more bedrooms are spread out for privacy.
Pin It
More plans by this designer/architect
ShareThis
Purchase Plans
© copyright by designer
First Floor Plan:
First Floor Plan
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor Plan:
Second Floor Plan
Plan Specification
Total Square Footage: 6,636
Main Level: 3,776
Second Level: 2,860
Bedrooms: 5
Baths: 4 Half: 2
Garages: 4
Width/Depth: 147 ft / 104 ft
Foundation: Slab
Get Your House Plans In Minutes!
NEW PDFs Now! Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
House Plan Pricing
$125.00
$3,000.00
PDFs Now! $3,150.00
$6,300.00
More details about our plan packages
Foundation Options
$0.00
Additional Plan Options
$15.00
$45.00
$100.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
• 2 Story Volume
• Arches
• Attached
• Bonus Room
• Breezeway
• Butler's Pantry
• Country Kitchen
• Courtyard
• Covered Front Porch
• Covered Rear Porch
• Deck
• Dining Room
• Double Vanity Sink
• Drive-under
• Exercise Room
• Family Room
• Fireplace
• Formal LR
• Foyer
• Great Room
• Guest Suite
• His and Hers Master Closets
• Home Office
• Kitchen Island
• Laundry 2nd Fl
• Loft / Balcony
• Master Bdrm Upstairs
• Mud Room
• Nook / Breakfast Area
• Open Floor Plan
• Oversized
• Peninsula / Eating Bar
• Rear-entry
• Separate Tub and Shower
• Sitting Area
• Slab
• Split Bedrooms
• Vaulted Ceilings
• Walk-in Closet
• Walk-in Pantry
• Workshop
Plan Details
General House Information
2
Number of Stories:
147' 0"
Width:
104' 4"
Depth:
Single
Dwelling Number:
1st Floor, 2nd Floor
Bonus Access:
Exterior Style
Mediterranean
European
Tuscan
Florida
Concrete
Facade
Stucco
Number of Rooms
5
Bedrooms:
4
Full Baths:
2
Half Baths:
Finished Square Footage
3,776 Sq. Ft.
Main Level:
2,860 Sq. Ft.
Upper Level:
6,636 Sq. Ft.
Total:
Unfinished Square Footage
1289 Sq. Ft.
Garage:
1269 Sq. Ft.
Porch:
295 Sq. Ft.
Deck:
34 Sq. Ft.
Patio:
GARAGE
Rear
Garage Location:
4
Garage Size:
Foundation
Slab
House And Ceiling Heights
12
First Floor Ceiling:
10
Second Floor Ceiling:
35' 0"
Maximum House Height:
Framing Information
Combination
Roof Framing:
8" Block/Wood
Exterior Wall Framing:
Roof Pitch
4:12
Primary:
4:12
Secondary:
Roof Load
35
Live:
50
Dead:
120
Wind:
Insulation (R)
19
Exterior Wall:
0
Interior Wall:
32
Ceiling:
0
Floor:
Number of Rooms
5
Bedrooms:
4
Full Baths:
2
Half Baths:
