Plan: 5028

Pin It
Similar plans: 4063, 5036, 4168, 5485
More plans by this designer/architect
ShareThis
Purchase Plans
© copyright by designer
First Floor Plan:




Plan Specification
Total Square Footage: 2,173
Main Level: 2,173
Bedrooms: 3
Baths: 2 Half: 1
Garages: 3
Width/Depth: 74 ft / 56 ft
Foundation: Basement Option - 1-2 week turnaround, Crawl Space Option - 1-2 week turnaround, Slab
House Plan Pricing
$99.00
$840.00
$1,030.00
$1,030.00
$2,060.00
More details about our plan packages
Foundation Options
$0.00
$450.00
$450.00
Additional Plan Options
$45.00
$15.00
$45.00
$75.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
  • 2 & 1/2 Baths
  • 3 Bedrooms
  • 3 Car Garage - Rear Side Entry
  • Arches
  • Attached
  • Built - In Media with Fireplace
  • Combination Kitchen / Family Room
  • Covered Patio with Decorative Columns
  • Covered Rear Porch
  • Dining Room
  • Double Vanity Sink
  • Family Room
  • Fireplace
  • Formal Dining Room
  • Formal LR
  • Foyer
  • Grand Foyer
  • Grand Master - Sitting Area
  • Great Room
  • His and Hers Master Closets
  • Kitchen Island
  • Large Laundry Room
  • Laundry 1st Fl
  • Linen Closets
  • Master Bdrm Main Floor
  • Mud Room
  • Nook / Breakfast Area
  • Open Floor Plan
  • Peninsula / Eating Bar
  • Rear Porch
  • Separate Tub and Shower
  • Split Bedrooms
  • Vaulted Ceilings
  • Walk-in Closet
  • Walk-in Pantry
Plan Details

General House Information
Number of Stories:1
Width:74' 4"
Depth:56' 0"
Dwelling Number:Single

Exterior Style
  • Contemporary
  • Beach
  • Mediterranean
  • Florida
  • European

Facade
  • Stucco

Number of Rooms
Bedrooms:3
Full Baths:2
Half Baths:1

Finished Square Footage
Main Level:2173 Sq. Ft.
Total: 2173 Sq. Ft.

Unfinished Square Footage
Garage:827 Sq. Ft.

Garage
Garage Type:Attached
Garage Size:3

Foundation
  • Basement Option - 1-2 week turnaround
  • Crawl Space Option - 1-2 week turnaround
  • Slab

House And Ceiling Heights
First Floor Ceiling:10
Second Floor Ceiling:0
Maximum House Height:0' 0"

Framing Information
Roof Framing:Truss
Exterior Wall Framing:2x4

Roof Pitch
Primary:7:12

INSULATION
  • Per IRC Climate Zones

Number of Rooms
Bedrooms:3
Full Baths:2
Half Baths:1
Architect's Preferred Products
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments
