Plan: 5069

Plan Specification
Total Square Footage: 2,052
Main Level: 2,052
Bedrooms: 3
Baths: 3 Half: 0
Garages: 2
Width/Depth: 60 ft / 50 ft
Foundation: Basement Option, Crawl Space Option, Slab
Pin It
© copyright by designer
Floor Plan:
Floor Plan



Similar plans: 8927, 3985
More plans by this designer/architect
ShareThis
Add to Favorites
Purchase Plans
PLAN DESCRIPTION Repeated arches give this one-story home plan a Mediterranean feel. Inside, a corner fireplace enhances the spacious Great room. For more intimate conversations, choose the den/living room. The roomy kitchen serves any meal with ease. Can you imagine a more deluxe master suite than this one? The corner garden tub is sure to soak your cares away.
Get Your House Plans In Minutes!
NEW PDFs Now!™ Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
10% Off All House Plans Through The End Of August !!! see details
House Plan Pricing
PDFs Now!™ $600.00
$840.00
$1,030.00
PDFs Now!™ $1,030.00
$2,060.00
More details about our plan packages
Foundation Options
$0.00
Additional Plan Options
$175.00
$45.00
$45.00
$75.00
Best Price Guarantee, learn more

Live Chat  |  Email
Key Features
• Arches
• Attached
• Covered Front Porch
• Covered Rear Porch
• Dining Room
• Family Room
• Fireplace
• Formal LR
• Foyer
• Laundry 1st Fl
• Master Bdrm Main Floor
• Nook / Breakfast Area
• Open Floor Plan
• Peninsula / Eating Bar
• Split Bedrooms
• Suited for view lot
• Walk-in Closet
Plan Details
General House Information
1
Number of Stories:
60' 0"
Width:
50' 0"
Depth:
Single
Dwelling Number:
None
Bonus Access:
Exterior Style
Contemporary
European
Mediterranean
Facade
Stucco
Number of Rooms
3
Bedrooms:
3
Full Baths:
Finished Square Footage
2,052 Sq. Ft.
Main Level:
2,052 Sq. Ft.
Total:
Unfinished Square Footage
414 Sq. Ft.
Garage:
135 Sq. Ft.
Porch:
146 Sq. Ft.
Patio:
GARAGE
Front
Garage Location:
2
Garage Size:
Foundation
Basement Option
Crawl Space Option
Slab
House And Ceiling Heights
9
First Floor Ceiling:
19' 5"
Maximum House Height:
Framing Information
Truss
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
6:12
Primary:
Insulation (R)
11
Exterior Wall:
0
Interior Wall:
19
Ceiling:
0
Floor:
Number of Rooms
3
Bedrooms:
3
Full Baths:
