Plan: 5124

This magnificent Mediterranean luxury mansion house plan is stunning. Balconies, rotundas, large decorative pillars, and varied ceiling treatments will draw you in. When you enter the two-story grand foyer, the view is inspiring. Flanked by the quiet study on the right and on the left is the elegant dining room with butlery for ease in serving. Off the dining room is a lounge with dome ceiling and wine room, while off the study is a circular office. A guest suite offers a walk-in closet and full bath, and sits adjacent to the utility room. The veranda sit off the dining room and study. Beyond the grand foyer is the bayed window music room with views and access to the courtyard. The family room provides two two-way fireplaces; one with the courtyard and one with the game room. The gourmet kitchen provides a free-standing island for additional counter space, with a breakfast bar that can be shared with the family room. A game room with built-in bar and full bath sits quietly behind the family room. A family bedroom across from the guest suite offers a walk-in closet and full bath. The luxurious master suite boasts a bayed window, trey ceiling, warming fireplace, courtyard access, grand master bath with his and hers vanities, separate shower, whirlpool, and large wardrobe with built-ins, cedar closet, exercise room, storage and a utility room. Upstairs, a family bedroom with built-in desk, walk-in closet, full bath and private balcony, shares space with the bonus room with sitting area and private balcony. This completes this luxury mansion house plan.
Pin It
More plans by this designer/architect
Purchase Plans

© copyright by designer
First Floor:

Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor:

Plan Specification
Total Square Footage: 9,253
Main Level: 8,273
Second Level: 980
Bedrooms: 4
Baths: 5 Half: 1
Garages: 5
Width/Depth: 151 ft / 120 ft
Foundation: Crawl Space, Slab
