Plan: 5185

This luxury mansion house plan opens to a lovely two-story foyer with curved stairs to the second level. A formal dining room with butlery offers ease in serving. The family gathering area consists of the kitchen, breakfast room and family room. The family room's center warming fireplace is flanked with built-ins and helps keep this area cozy. Access to the outdoor lounge can be achieved through the family room. The gourmet kitchen provides a free-standing island for additional counter space. The breakfast bar can be shared with the family room and breakfast area. The large master suite has a bayed window sitting area and access to the outdoor lounge, lavish master bath with his and hers vanities, snail shower, corner garden tub, and large his and hers wardrobes. Upstairs, three family bedrooms with walk-in closets and full baths share space with a game room, balcony, and overlook. A circular staircase from the overlook will take you back to the first level, or stay and enjoy the stunning views to the main level below, completing this luxury mansion house plan.
Pin It
More plans by this designer/architect
ShareThis
Purchase Plans

© copyright by designer
First Floor:


Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor:

Plan Specification
Total Square Footage: 4,463
Main Level: 2,817
Second Level: 1,646
Bedrooms: 4
Baths: 4
Garages: 4
Width/Depth: 86 ft / 75 ft
Foundation: Crawl Space, Slab
House Plan Pricing
$1,015.00
$1,515.00
$1,715.00
$2,275.00
More details about our plan packages
Foundation Options
$0.00
$250.00
Additional Plan Options
$200.00
$125.00
$200.00
Promotional Items
$25.00
Size:
Color:
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
  • Arches
  • Attached
  • Country Kitchen
  • Covered Front Porch
  • Covered Rear Porch
  • Deck
  • Dining Room
  • Double Vanity Sink
  • Family Room
  • Fireplace
  • Foyer
  • Front Porch
  • His and Hers Master Closets
  • Home Office
  • Laundry 1st Fl
  • Library/Media Rm
  • Master Bdrm Main Floor
  • Nook / Breakfast Area
  • Open Floor Plan
  • Rear Porch
  • Separate Tub and Shower
  • Side-entry
  • Sitting Area
  • Slab
Plan Details

General House Information
Number of Stories:2
Width:86' 0"
Depth:75' 0"
Dwelling Number:Single

Exterior Style
  • Traditional

Number of Rooms
Bedrooms:4
Full Baths:4

Finished Square Footage
Main Level:2817 Sq. Ft.
Upper Level: 1646 Sq. Ft.
Total: 4463 Sq. Ft.

Unfinished Square Footage
Garage:1175 Sq. Ft.
Porch:77 Sq. Ft.
Deck:504 Sq. Ft.
Patio:721 Sq. Ft.

Garage
  • Garage Type:
Garage Size:4

Foundation
  • Crawl Space
  • Slab

House And Ceiling Heights
First Floor Ceiling:10
Second Floor Ceiling:10
Maximum House Height:43' 0"

Framing Information
Roof Framing:Stick
Exterior Wall Framing:2x4

Roof Pitch
Primary:12
Secondary:20

INSULATION
Exterior Wall:0
Interior Wall:0
Ceiling:0
Floor:0

Number of Rooms
Bedrooms:4
Full Baths:4
