Plan Specification: HHF-5237

Total Square Footage: 1,105

Main Level: 652

Second Level: 453

Bedrooms: 1

Baths: 2

Garages: 2

Width: 27 ft Depth: 29 ft

Foundation: Slab Foundation-Included


Pricing Options Click here...

Main Plan Photo
© copyright by designer

Plan: HHF-5237

The perfect plan for a get-away spot, this is a cozy home and designed specifically for sites that slope up from the front. By situating the double garage underneath, the site is accommodated, but the design is not compromised. Outside entry is accomplished from the back of the plan, or via a staircase leading up from the garage. And even though the plan is small, it lives very well. Special features, such as a main-level bath with shower, a huge living area with fireplace, window seat and media center, and a commodious kitchen with built-in desk and deck access make it comfortable. The upper level is dominated by the master suite, which has a vaulted bedroom with built-in bookcases and a window seat, and a vaulted bath with spa tub, separate shower and huge walk-in closet. An alcove upstairs provides space for a washer/dryer. A built-in desk in the upper-level hall is also a nice touch.

ShareThis
$50 off any House Plan through midnight tonight! see details
Additional Images

Plan Pricing Packages
HOUSE PLAN SETS

 Basic Package    $700.00
 Construction Package    $800.00
 Modification Package: PDF    $920.00
 Modification Package: CAD    $1,550.00
FOUNDATION OPTIONS

 Slab Foundation-Included  $0.00
ADDITIONAL PLAN OPTIONS

 Additional Sets  $40.00
 Full Reverse Sets  $100.00
PROMOTIONAL ITEMS

 Custom Adult T-shirt  $25.00
Size:
Color:
Best Price Guarantee, learn more
For more details about our plan packages click here



Email Us   Call Us   Live Chat

Key Features
  • Country Kitchen
  • Covered Rear Porch
  • Deck
  • Detached
  • Drive-under
  • Fireplace
  • Foyer
  • Great Room
  • Laundry 2nd Fl
  • Master Bdrm Upstairs
  • Open Floor Plan
  • Peninsula / Eating Bar
  • Separate Tub and Shower
  • Vaulted Ceilings
  • Walk-in Closet
  • Walk-in Pantry
  • With Living Space
  • Workshop
Need to make changes?
Call for a free modification quote
877-895-5299
or use this quote form
Architect's Preferred Products:
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments
10% off ALL online house plan packages! Promo Code: Thanks2011

© copyright by designer
First Floor Plan:





© copyright by designer
Second Floor Plan:


© copyright by designer
Lower Level:

Top

Plan Details

General House Information
Number of Stories:2
Width:27' 0"
Depth:29' 6"
Dwelling Number:Single
Bonus Access:None

Exterior Style
  • Craftsman
  • Mountain
  • Vacation
  • PDFs Fast!

Facade
  • Siding

Number of Rooms
Bedrooms:1
Full Baths:2

Finished Square Footage
Main Level:652 Sq. Ft.
Upper Level: 453 Sq. Ft.
Total: 1105 Sq. Ft.

Unfinished Square Footage
Garage:709 Sq. Ft.

Garage
Garage Type:Detached
Garage Size:2


Foundation
  • Slab Foundation-Included

House And Ceiling Heights
First Floor Ceiling:9
Second Floor Ceiling:11
Maximum House Height:33' 2"

Framing Information
Roof Framing:Truss
Exterior Wall Framing:2x6

Roof Pitch
Primary:8/12
Secondary:5/12

Roof Load
Live:25
Dead:15
Wind:0

INSULATION
  • Per IRC Climate Zones

Number of Rooms
Bedrooms:1
Full Baths:2
