Plan Specification: HHF-5463

Total Square Footage: 3,412

Main Level: 2,640

Second Level: 772

Bedrooms: 4

Baths: 3        Half: 1

Garages: 2

Width: 40 ft Depth: 80 ft

Foundation: Crawl Space, Slab

Pricing Options Click here...

Main Plan Photo
© copyright by designer

Plan: HHF-5463

This is a great empty nester home or home if you have an in-law living with you. This lovely luxury house plan is designed for a narrow lot without losing amenities.From the two-story foyer you will be able to see all the way through to the fireplace in the family room that sits all the way at the rear of this house plan. Adjacent to the foyer is the vaulted ceiling study with a quiet sitting area. Through the barrel vaulted ceilings is the gallery and elegant dining room set off with large decorative pillars. The dining room has direct entry to the butlery, pantry and kitchen for ease in serving. The large kitchen also offers a free-standing island with sink, dishwasher, and granite counter tops. The breakfast area shares the vaulted ceiling with the family room. The window seat in the breakfast and warming corner fireplace are some of the amenities that make this large area so cozy. A door from the family room leads to the outdoor patio. This completes the left side of this luxury house plan. On the right side, beginning at the back is the master suite with access to the patio. Its vaulted ceiling adds volume to this suite. The French doors lead into a lavish master bath with his and hers vanities, a separate shower and tub and a large wardrobe. Two family bedrooms each have walk-in closets and share a family bath. The large utility room with utility tub and two-car garage complete this lovely luxury house plan. Alternate elevations are Granite Peak and Granite Ridge.

Additional Images

Plan Pricing Packages

 One Study Set    $725.00
 Plan PDF Package    $1,075.00
 Five Sets    $1,275.00
 CAD File    $1,620.00

 Slab  $0.00
 Crawl Space  $250.00

 Additional Sets  $75.00
 Mirror Reverse  $200.00
 Artist Rendering  $150.00

 Custom Adult T-shirt  $25.00
Best Price Guarantee, learn more
For more details about our plan packages click here

Email Us   Call Us   Live Chat
Key Features
  • Attached
  • Dining Room
  • Double Vanity Sink
  • Family Room
  • Front Porch
  • Home Office
  • Laundry 1st Fl
  • Master Bdrm Main Floor
  • Slab
Need to make changes?
Call for a free modification quote
or use this quote form
Architect's Preferred Products:
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments

© copyright by designer
First Floor:

© copyright by designer
Second Floor:

Plan Details
General House Information
Number of Stories:2
Width:40' 0"
Depth:80' 0"
Dwelling Number:Single
Exterior Style
  • European
  • Traditional
Number of Rooms
Full Baths:3
Half Baths:1
Finished Square Footage
Main Level:2640 Sq. Ft.
Upper Level: 772 Sq. Ft.
Total: 3412 Sq. Ft.
Unfinished Square Footage
Garage:420 Sq. Ft.
  • Garage Type:
Garage Size:2
  • Crawl Space
  • Slab
House And Ceiling Heights
First Floor Ceiling:10
Second Floor Ceiling:9
Maximum House Height:29' 0"
Framing Information
Roof Framing:Stick
Exterior Wall Framing:2x4
Roof Pitch
Exterior Wall:0
Interior Wall:0
Number of Rooms
Full Baths:3
Half Baths:1
