front Rear Elevation Basement first floor second floor
© copyright by designer

Plan: 5647

Plan Specification
Total Square Footage: 1,114
Main Level: 854
Second Level: 260
Lower Level: 344
Bedrooms: 3
Baths: 2 Half: 0
Garages: 1
Width/Depth: 24 ft / 38 ft
Foundation: Basement, Crawl Space, Slab
Pin It
© copyright by designer
Basement:
Basement
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
first floor:
first floor
© copyright by designer
second floor:
second floor
Similar plans: 5797, 5630
More plans by this designer/architect
ShareThis
Add to Favorites
Purchase Plans
Get Your House Plans In Minutes!
NEW PDFs Now!™ Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
House Plan Pricing
$420.00
$483.00
$567.00
$698.00
More details about our plan packages
Foundation Options
$0.00
$0.00
$0.00
Additional Plan Options
$175.00
$50.00
$50.00
$75.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
• Attached
• Drive-under
• Front Porch
• Suited for narrow lot
Plan Details
General House Information
2
Number of Stories:
24' 4"
Width:
38' 6"
Depth:
Single
Dwelling Number:
Exterior Style
Beach
Contemporary
Lake
Number of Rooms
3
Bedrooms:
2
Full Baths:
Finished Square Footage
854 Sq. Ft.
Main Level:
260 Sq. Ft.
Upper Level:
344 Sq. Ft.
Lower Level:
1,114 Sq. Ft.
Total:
Unfinished Square Footage
510 Sq. Ft.
Garage:
GARAGE
Front
Garage Location:
1
Garage Size:
Foundation
Basement
Crawl Space
Slab
Framing Information
Stick
Roof Framing:
2x4 or 2x6
Exterior Wall Framing:
Roof Load
30
Live:
15
Dead:
100
Wind:
Insulation (R)
19
Exterior Wall:
0
Interior Wall:
38
Ceiling:
19
Floor:
Number of Rooms
3
Bedrooms:
2
Full Baths:
