Plan Specification: HHF-7055

Total Entire Building: 3,316

Total Living Per Unit: 829

Main Level: 435

Second Level: 394

Bedrooms: 2

Baths: 1        Half: 1

Garages:

Width: 61 ft Depth: 29 ft

Foundation: Crawl Space, Slab


Pricing Options Click here...
Main Plan Photo
© copyright by designer

Plan: HHF-7055

4 Unit Complex-- 3316 Total H/C
This multi-family design from Nelson Design Group features four housing units. On the main floor of each unit, the generous great room merges with the kitchen area. A half bath, laundry area, and rear patio complete the main floor of each home. Two bedrooms and a full bath are available on the upper floor of each unit, along with access to an attic storage area. This design may be just the multi-family plan you’ve been looking for.

ShareThis
Additional Images

See all 2 photos and rear view
Plan Pricing Packages
HOUSE PLAN SETS
 One Set  $1,050.00
 Four Sets  $1,250.00
 Eight Sets  $1,400.00
 PDF File Package  $1,490.00
 Reproducibles  $2,150.00
 CADD  $3,308.00
FOUNDATION OPTIONS
 Crawl Space  $0.00
ADDITIONAL PLAN OPTIONS
 Ceiling Joist Framing Plan  $100.00
 First Floor Framing Plan  $100.00
 Materials List  $125.00
 Roof Framing Plan  $100.00
 Right Reading Reverse  $50.00
 Additional Sets  $50.00
PROMOTIONAL ITEMS
 Custom Adult T-shirt  $25.00
Size:
Color:
Best Price Guarantee, learn more
For more details about our plan packages click here



Email Us   Call Us   Live Chat

Key Features
  • CADD
  • Detached
  • Vellum set
Need to make changes?
Call for a free modification quote
877-895-5299
or use this quote form

© copyright by designer
First Floor:





© copyright by designer
Second Floor:

Top

Plan Details

General House Information
Number of Stories:2
Width:61' 3"
Depth:29' 6"
Dwelling Number:Multi-Family

Exterior Style
  • Traditional

Number of Rooms
Bedrooms:2
Full Baths:1
Half Baths:1

Finished Square Footage
Main Level:435 Sq. Ft.
Upper Level: 394 Sq. Ft.
Total: 829 Sq. Ft.

Garage
  • Garage Size:


Foundation
  • Crawl Space
  • Slab

House And Ceiling Heights
First Floor Ceiling:8
Second Floor Ceiling:8
Maximum House Height:25' 4"

Framing Information
Roof Framing:Stick
Exterior Wall Framing:2x4

Roof Pitch
Primary:7:12

Roof Load
Live:30
Dead:15
Wind:90

INSULATION
Exterior Wall:13
Interior Wall:0
Ceiling:30
Floor:19

Number of Rooms
Bedrooms:2
Full Baths:1
Half Baths:1
