Plan: 8023

Pin It
Similar plans: 5999, 6478
More plans by this designer/architect
ShareThis
Purchase Plans

© copyright by designer
1st Floor Plan:


Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
2nd Floor Plan:

Plan Specification
Total Square Footage: 1,746
Main Level: 1,278
Second Level: 468
Bedrooms: 3
Baths: 2 Half: 1
Garages: 2
Width/Depth: 52 ft / 46 ft
Foundation: Slab
House Plan Pricing
$675.00
$825.00
$1,025.00
$1,540.00
More details about our plan packages
Foundation Options
$0.00
Additional Plan Options
$80.00
$120.00
Promotional Items
$25.00
Size:
Color:
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
  • 2 Story Grand Salon
  • 2 Story Great Room
  • Attached
  • Columns - Inside
  • Columns - Outside
  • Front Porch
  • Master Bdrm Main Floor
  • Optional Bonus Room
  • Vaulted Breakfast Room
  • Vaulted Ceilings in Master
  • Vaulted Grand Salon
  • Vaulted Great Room
Plan Details

General House Information
Number of Stories:2
Width:52' 0"
Depth:46' 0"
Dwelling Number:Single

Exterior Style
  • Traditional
  • Cape Cod
  • Country
  • Farm House
  • Texas

Number of Rooms
Bedrooms:3
Full Baths:2
Half Baths:1

Finished Square Footage
Main Level:1278 Sq. Ft.
Upper Level: 468 Sq. Ft.
Total: 1746 Sq. Ft.

Unfinished Square Footage
Garage:377 Sq. Ft.
Bonus Room:169 Sq. Ft.

Garage
Garage Type:Attached
Garage Size:2

Foundation
  • Slab

House And Ceiling Heights
First Floor Ceiling:9
Second Floor Ceiling:8
Maximum House Height:24' 8"

Framing Information
Roof Framing:Stick
Exterior Wall Framing:2x4

Roof Pitch
Primary:12/10

Roof Load
Live:40#
Dead:12#

INSULATION
  • Per IRC Climate Zones

Number of Rooms
Bedrooms:3
Full Baths:2
Half Baths:1
Architect's Preferred Products
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments
