Plan Specification: HHF-8757

Total Entire Building: 2,010

Total Living Per Unit: 1,005

Main Level: 516

Second Level: 489

Bedrooms: 2

Baths: 1        Half: 1

Garages: 0

Width: 33 ft Depth: 39 ft

Foundation: Basement, Daylight Basement


Pricing Options Click here...

Main Plan Photo
© copyright by designer

Plan: HHF-8757

Nelson Design Group has created a southern traditional duplex plan with the appearance of a two story single family home. The front door leads to a foyer concealing two separate living quarters. Each living quarter has a great room with large closet that can be used as a computer nook, a spacious kitchen with dining area, and a rear access to a patio with storage room. Travel upstairs and find a full bath, large storage closet and two bedrooms - one with a walk-in closet and French doors to the balcony.

ShareThis
Additional Images

Plan Pricing Packages
HOUSE PLAN SETS

 One Set    $670.00
 Four Sets    $780.00
 Eight Sets    $945.00
 PDF File Package    $1,450.00
 Reproducibles    $1,450.00
 CADD    $2,235.00
FOUNDATION OPTIONS

 Basement  $0.00
ADDITIONAL PLAN OPTIONS

 Additional Sets  $50.00
 Ceiling Joist Framing Plan  $100.00
 First Floor Framing Plan  $100.00
 Materials List  $125.00
 Roof Framing Plan  $100.00
 Right Reading Reverse  $50.00
PROMOTIONAL ITEMS

 Custom Adult T-shirt  $25.00
Size:
Color:
Best Price Guarantee, learn more
For more details about our plan packages click here



Email Us   Call Us   Live Chat

Key Features
  • CADD
  • Front Porch
  • Vellum set
Need to make changes?
Call for a free modification quote
877-895-5299
or use this quote form

© copyright by designer
First Floor:





© copyright by designer
Second Floor:

Top

Plan Details

General House Information
Number of Stories:2
Width:33' 2"
Depth:39' 2"
Dwelling Number:Duplex

Exterior Style
  • Traditional
  • Country
  • Southern

Number of Rooms
Bedrooms:2
Full Baths:1
Half Baths:1

Finished Square Footage
Main Level:516 Sq. Ft.
Upper Level: 489 Sq. Ft.
Total: 1005 Sq. Ft.

Unfinished Square Footage
Garage:52 Sq. Ft.
Porch:132 Sq. Ft.

Garage
  • Garage Type:
Garage Size:0


Foundation
  • Basement
  • Daylight Basement

House And Ceiling Heights
First Floor Ceiling:8
Second Floor Ceiling:8
Maximum House Height:38' 2"

Framing Information
Roof Framing:Stick
Exterior Wall Framing:2x4

Roof Pitch
Primary:6:12

Roof Load
Live:30
Dead:15
Wind:90

INSULATION
Exterior Wall:13
Interior Wall:0
Ceiling:30
Floor:19

Number of Rooms
Bedrooms:2
Full Baths:1
Half Baths:1
