Plan Specification: HHF-9011

Total Square Footage: 3,594

Main Level: 3,594

Bedrooms: 5

Baths: 4

Garages: 3

Width: 77 ft Depth: 131 ft

Foundation: Slab

Pricing Options Click here...

Main Plan Photo
© copyright by designer

Plan: HHF-9011

Entering through a high arched breezeway, with courtyards to either side, you will find a study/bedroom 4 off to one side of the foyer and bedroom 3 and master bedroom to the other. The casita/bedroom 5 enters off of the right courtyard. Straight ahead, you enter the vaulted living area with windows overlooking a large covered patio complete with an outdoor kitchen. The kitchen is open to the living and the dining area with stone arches at the second island and a stone arched cooktop. Off the dining room is bedroom 2 and the game room. The master suite has a step up ceiling feature and a built in desk/bar and has access to the courtyard. The master bathroom is complete with a corner tub, shower and separate vanities along with a spacious walk in closet.

Additional Images
Plan Pricing Packages

 PDF- Bid Set    $800.00
 Four Sets    $900.00
 Eight Sets    $1,000.00
 PDF- Construction Set    $1,150.00

 Slab  $150.00

 Mirror Reverse  $50.00

 Custom Adult T-shirt  $25.00
Best Price Guarantee, learn more
For more details about our plan packages click here

Email Us   Call Us   Live Chat
Key Features
  • 2 Story Volume
  • Arches
  • Attached
  • Breezeway
  • Courtyard
  • Covered Front Porch
  • Covered Rear Porch
  • Detached
  • Dining Room
  • Double Vanity Sink
  • Family Room
  • Fireplace
  • Foyer
  • Front Porch
  • Guest Suite
  • In-law Suite
  • Kitchen Island
  • Laundry 1st Fl
  • Master Bdrm Main Floor
  • Nook / Breakfast Area
  • Open Floor Plan
  • Oversized
  • Peninsula / Eating Bar
  • Rear Porch
  • Rear-entry
  • Rec Room
  • Separate Tub and Shower
  • Side-entry
  • Slab
  • Split Bedrooms
  • Vaulted Ceilings
  • Walk-in Closet
  • Walk-in Pantry
Need to make changes?
Call for a free modification quote
or use this quote form
Architect's Preferred Products:
ULTREX® Fiberglass Windows & Doors
Decorative Millwork and Columns
Classic-Craft® American Collection™ Fiberglass Entry Door
Prefinished Hardwood Flooring
Decorative Window Treatments

© copyright by designer
Floor Plan:

Plan Details
General House Information
Number of Stories:1
Width:77' 2"
Depth:131' 4"
Dwelling Number:Single
Exterior Style
  • Mediterranean
  • Spanish
  • Tuscan
  • Builders
Number of Rooms
Full Baths:4
Finished Square Footage
Main Level:3594 Sq. Ft.
Total: 3594 Sq. Ft.
Unfinished Square Footage
Garage:866 Sq. Ft.
Porch:142 Sq. Ft.
Patio:399 Sq. Ft.
  • Garage Type:
Garage Size:3
  • Slab
House And Ceiling Heights
First Floor Ceiling:10
Maximum House Height:0' 0"
Framing Information
Roof Framing:Stick
Exterior Wall Framing:2x4 or 2x6
Roof Pitch
  • Per IRC Climate Zones
Number of Rooms
Full Baths:4
