House Plan: DFD-10047

See All 5 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
632
BEDS
1
BATHS
1
STORIES
2
CARS
3
PLANS FROM $1,374
For questions and help, live chat, email or call us at 877-895-5299
Floor Plans
Click to Zoom In on Floor Plan

About House Plan 10047:
House Plan 10047, is a versatile garage and coach house, perfect as a standalone dwelling or property addition. The lower level features a three-vehicle garage, workshop, and well-designed living space with a foyer, efficient kitchen with an eating bar, and a bright living room with a wide-silled window. A stacked laundry nook adds convenience near the staircase. Upstairs, the primary bedroom provides a private retreat with French doors opening to a sundeck, while the three-piece bath includes a shower stall with a built-in bench.
House Plan Pricing
STEP 1 Select Your Package

PDF Single Build


Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $1,374
Most recommended package

5 Printed Sets + PDF


Digital plan emailed to you in PDF format that allows for printing copies on a home printer or local print shop and sharing with contractors, subs, decorators, and more. PLUS five printed sets shipped and delivered 3-5 business days.

5 Printed Sets + PDF $1,543
Digital plans plus 5 printed sets

CAD Single Build


2D electronic computer files, completely editable, for design professional use, when making extensive modifications or in the event engineering is required in the area where you are building.

CAD Single Build $2,551
2D electronic editable computer files

CAD Unlimited Build


2D electronic computer files, completely editable, for design professional use when making extensive modifications; multi-license allows unlimited builds

CAD Unlimited Build $5,004
2D electronic editable computer files
STEP 2 Need To Reverse This Plan?
STEP 3 CHOOSE YOUR FOUNDATION
STEP 4 OPTIONAL ADD-ONS
Subtotal
$1374
FREE SHIPPING

Note: A

Plan Details
See All Details
Finished Square Footage
348 Sq. Ft.
Main Level:
284 Sq. Ft.
Upper Level:
632 Sq. Ft.
Total:
Room Details
1
Bedrooms:
1
Full Baths:
General House Information
2
Number of Stories:
48' 6"
Width:
27' 6"
Depth:
Single
Dwelling Number:
1st Floor
Bonus Access:
Unfinished Square Footage
715 Sq. Ft.
Garage:
70 Sq. Ft.
Front Porch:
72 Sq. Ft.
Deck:
GARAGE
Front
Garage Location:
3
Garage Size:
Exterior Style
Craftsman
Collections
Affordable
Architects Choice
Budget
Builders
Canada
Empty Nester
First Home
Open Floor Plan
Foundation
Basement
Crawlspace
Slab
Walkout Basement
Framing Information
Truss
Roof Framing:
2x6
Exterior Wall Framing:
Roof Pitch
4/12
Primary:
Insulation (R)
Per IRC Climate Zones
House And Ceiling Heights
8
First Floor Ceiling:
8
Second Floor Ceiling:
20' 8"
Maximum House Height:
Key Features
Attached
Country Kitchen
Courtyard
Deck
Front-entry
Laundry 1st Fl
Primary Bdrm Upstairs
Open Floor Plan
Oversized
Peninsula / Eating Bar
Suited for narrow lot
Suited for view lot
Tandem
U-Shaped
Workshop
