House Plan: 2571

Plan Specification
Total Square Footage: 2,262
Main Level: 1,302
Second Level: 960
Bedrooms: 3
Baths: 2 Half: 1
Garages: 2
Width/Depth: 40 ft / 40 ft
Foundation: Slab Foundation-Included
ENERGY STAR APPROVED
Pin It
View typical construction drawings by this designer >
© copyright by designer
First Floor Plan:
First Floor Plan
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor Plan:
Second Floor Plan
© copyright by designer
Lower Level:
Lower Level
Similar plans: 2572
More plans by this designer/architect
Add to Favorites
Purchase Plans
House Plan Pricing
$1,153.00
$1,503.00
$1,678.00
$1,728.00
$3,006.00
More details about our plan packages
Foundation Options
$0.00
Additional Plan Options
$175.00
$45.00
$175.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
• Attached
• Daylight Basement
• Deck
• Drive-under
• Great Room
• Home Office
• Kitchen Island
• Laundry 1st Fl
• Loft / Balcony
• Master Bdrm Upstairs
• Nook / Breakfast Area
• Oversized
• Suited for narrow lot
• Suited for sloping lot
• Suited for view lot
• Vaulted Ceilings
• Walkout Basement
Plan Details
General House Information
2
Number of Stories:
40' 0"
Width:
40' 0"
Depth:
Single
Dwelling Number:
Exterior Style
Beach
Traditional
Number of Rooms
3
Bedrooms:
2
Full Baths:
1
Half Baths:
Finished Square Footage
1,302 Sq. Ft.
Main Level:
960 Sq. Ft.
Upper Level:
2,262 Sq. Ft.
Total:
Unfinished Square Footage
1242 Sq. Ft.
Garage:
36 Sq. Ft.
Deck:
GARAGE
Under
Garage Location:
2
Garage Size:
Foundation
Slab Foundation-Included
House And Ceiling Heights
9' 1"
First Floor Ceiling:
9' 1"
Second Floor Ceiling:
36' 0"
Maximum House Height:
Framing Information
2x6
Exterior Wall Framing:
Roof Pitch
6/12
Primary:
Roof Load
25
Live:
15
Dead:
Insulation (R)
21
Exterior Wall:
0
Interior Wall:
38
Ceiling:
25
Floor:
Number of Rooms
3
Bedrooms:
2
Full Baths:
1
Half Baths:
