House Plan: 4688

Plan Specification
Total Entire Building: 3,834
Total Living Per Unit: 1,917
Main Level: 2,066
Second Level: 1,768
Bedrooms: 3
Baths: 3 Half: 0
Garages: 1
Width/Depth: 38 ft / 63 ft
Foundation: Crawlspace, Slab
Pin It
Main floor Plan:
Main floor Plan
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Upper Floor Plan:
Upper Floor Plan
© copyright by designer
Lower Floor Plan:
Lower Floor Plan
Similar plans: 5340
More plans by this designer/architect
Purchase Plans
PLAN DESCRIPTION Modern designs enhance this practical duplex, offering affordable access to style and comfort. Each side of this plan is equally as spacious, offering 1,917 square feet each, as well as 3 large bedrooms and an open concept design. Both units begin with a drive-under garage, making this plan great for a sloped lot. The main levels each have their own eat-in kitchens and living rooms, along with fully-stocked guest suites. Upstairs has a bit of a surprise in the form of 2 separate master suites. Each with their own full bath and walk-in closets, these spaces are exceedingly comfortable.
House Plan Pricing
$1,919.00
$2,269.00
$2,444.00
$2,494.00
$4,538.00
More details about our plan packages
Foundation Options
$0.00
$260.00
Additional Plan Options
$45.00
$175.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
• 2 Master Suites
• Attached
• Crawlspace
• Double Vanity Sink
• Drive-under
• Fireplace
• Foyer
• Guest Suite
• His and Hers Master Closets
• In-law Suite
• Kitchen Island
• Laundry 2nd Fl
• Loft / Balcony
• Master Bdrm Upstairs
• No Porch
• Peninsula / Eating Bar
• Storage Space
Plan Details
General House Information
3
Number of Stories:
38' 0"
Width:
63' 0"
Depth:
Duplex
Dwelling Number:
Exterior Style
Contemporary
Modern
Number of Rooms
3
Bedrooms:
3
Full Baths:
Finished Square Footage
2,066 Sq. Ft.
Main Level:
1,768 Sq. Ft.
Upper Level:
1,917 Sq. Ft.
Total:
Unfinished Square Footage
886 Sq. Ft.
Garage:
GARAGE
Under
Garage Location:
1
Garage Size:
Foundation
Crawlspace
Slab
House And Ceiling Heights
9
First Floor Ceiling:
8
Second Floor Ceiling:
27' 0"
Maximum House Height:
Framing Information
Truss
Roof Framing:
2x6
Exterior Wall Framing:
Roof Pitch
9/12
Primary:
Roof Load
25
Live:
15
Dead:
Insulation (R)
Per IRC Climate Zones
Number of Rooms
3
Bedrooms:
3
Full Baths:
