House Plan: 5143

Plan Specification
Total Square Footage: 1,670
Main Level: 1,670
Bedrooms: 3
Baths: 2 Half: 0
Garages: 2
Width/Depth: 70 ft / 46 ft
Foundation: Basement, Crawl Space, Slab
Pin It
© copyright by designer
First Floor Plan:
First Floor Plan



Similar plans: 5142, 3653, 5139, 5374
More plans by this designer/architect
ShareThis
Add to Favorites
Purchase Plans
PLAN DESCRIPTION Open living spaces and a large laundry room that provides a huge amount of storage. The storage in the laundry room is replaced by the stair with the basement option. Built-ins surround the fireplace in the greatroom. A corner walk-in pantry is provided in the kitchen.
Get Your House Plans In Minutes!
NEW PDFs Now!™ Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
House Plan Pricing
$870.00
$940.00
PDFs Now!™ $1,100.00
$1,900.00
More details about our plan packages
Foundation Options
PDFs Now!™ available $0.00
PDFs Now!™ available $0.00
PDFs Now!™ available $0.00
Additional Plan Options
$175.00
$55.00
$65.00
$255.00
$255.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
• Attached
• Basement
• Covered Front Porch
• Covered Rear Porch
• Crawlspace
• Fireplace
• Foyer
• Front Porch
• Great Room
• His and Hers Master Closets
• Laundry 1st Fl
• Master Bdrm Main Floor
• Nook / Breakfast Area
• Open Floor Plan
• Peninsula / Eating Bar
• Rear Porch
• Separate Tub and Shower
• Side-entry
• Slab
• Storage Space
• Suited for corner lot
• Suited for view lot
• Walk-in Closet
• Walk-in Pantry
Plan Details
General House Information
1
Number of Stories:
70' 0"
Width:
46' 0"
Depth:
Single
Dwelling Number:
Exterior Style
Country
Ranch
Southern
Facade
Siding
Number of Rooms
3
Bedrooms:
2
Full Baths:
Finished Square Footage
1,670 Sq. Ft.
Main Level:
1,670 Sq. Ft.
Total:
Unfinished Square Footage
380 Sq. Ft.
Garage:
50 Sq. Ft.
Storage:
418 Sq. Ft.
Porch:
GARAGE
Front
Garage Location:
2
Garage Size:
Foundation
Basement
Crawl Space
Slab
House And Ceiling Heights
9
First Floor Ceiling:
23' 0"
Maximum House Height:
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
8/12
Primary:
Roof Load
30
Live:
15
Dead:
Insulation (R)
Per IRC Climate Zones
Number of Rooms
3
Bedrooms:
2
Full Baths:
