House Plan: DFD-5828

Pin It
See All 6 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
2,753
BEDS
4
BATHS
3.5
STORIES
1.5
CARS
2
HOUSE PLANS SALE
START AT  $1,162.00
For questions and help, live chat, email or call us at 877-895-5299
First Floor
Second Floor
Floor Plans
Click to Zoom In on Floor Plan

About House Plan 5828:
Empty nesters wanted. This Tudor style cottage with a first floor master bedroom suite is ideal for the couple who wants to scale down but have room for the family when they visit. A second floor that can accommodate a large family makes this ideal.
ZIP CODE RESTRICTED IN 30080

House Plan Pricing
STEP 1 Select Your Package

PDF Bid Set

Home plans stamped "NOT FOR CONSTRUCTION" for cost estimating and bidding purposes only; a minimum 5 set plan package must be purchased within 90 days for a license to build plan set; a credit will be applied towards your house plan upgrade

PDF Bid Set $900
Digital set of plans for bidding purposes only

PDF Single Build

Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $1,400
Most recommended package

5 Printed Sets

Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets $1,550
Five printed sets of house plans
STEP 2 CHOOSE YOUR FOUNDATION
STEP 3 OPTIONAL ADD-ONS
Subtotal
$1400
FREE SHIPPING

Detailed Plan Packages & Pricing
Our Structural Detail & IRC Guarantee
Architect's Preferred Home Products
Plan Details
See All Details
Finished Square Footage
1,622 Sq. Ft.
Main Level:
1,131 Sq. Ft.
Upper Level:
2,753 Sq. Ft.
Total:
Room Details
4
Bedrooms:
3
Full Baths:
1
Half Baths:
General House Information
1.5
Number of Stories:
39' 6"
Width:
76' 0"
Depth:
Single
Dwelling Number:
Unfinished Square Footage
528 Sq. Ft.
Garage:
72 Sq. Ft.
Storage:
192 Sq. Ft.
Deck:
424 Sq. Ft.
Bonus Room:
GARAGE
Rear
Garage Location:
2
Garage Size:
Exterior Style
Bungalow
Cottage
French Country
Collections
Empty Nester
First Home
Old House Classics
Split Bedroom
Foundation
Crawl Space
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
12/12
Primary:
Roof Load
20
Live:
10
Dead:
Insulation (R)
Per IRC Climate Zones
House And Ceiling Heights
10
First Floor Ceiling:
8
Second Floor Ceiling:
28' 0"
Maximum House Height:
Key Features
Attached
Basement
Bonus Room
Covered Front Porch
Deck
Dining Room
Double Vanity Sink
Fireplace
Great Room
Guest Suite
Kitchen Island
Laundry 1st Fl
Loft / Balcony
Primary Bdrm Main Floor
Nook / Breakfast Area
Open Floor Plan
Peninsula / Eating Bar
Rear-entry
Separate Tub and Shower
Slab
Suited for corner lot
Suited for narrow lot
Unfinished Space
Vaulted Ceilings
Walk-in Closet
Walk-in Pantry
