Plan: 2766

Pin It
Similar plans: 2768, 2770, 5899
More plans by this designer/architect
ShareThis
Purchase Plans
© copyright by designer
First Floor Plan:

Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor Plan:

Plan Specification
Total Entire Building: 2,972
Total Living Per Unit: 1,486
Main Level: 704
Second Level: 782
Bedrooms: 3
Baths: 2 Half: 1
Garages: 2
Width/Depth: 28 ft / 47 ft
Foundation: Basement, Crawlspace, Slab
House Plan Pricing
$1,000.00
$1,100.00
$1,495.00
$2,300.00
More details about our plan packages
Foundation Options
$0.00
$160.00
$325.00
Additional Plan Options
$40.00
$100.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
  • 2 Story Volume
  • Attached
  • Basement
  • Country Kitchen
  • Crawlspace
  • Dining Room
  • Double Vanity Sink
  • Fireplace
  • Foyer
  • Front Porch
  • Great Room
  • Laundry 2nd Fl
  • Master Bdrm Upstairs
  • Open Floor Plan
  • Peninsula / Eating Bar
  • Slab
  • Vaulted Ceilings
Plan Details

General House Information
Number of Stories:2
Width:28' 0"
Depth:47' 0"
Dwelling Number:Duplex
Bonus Access:None

Exterior Style
  • Traditional
  • Colonial
  • PDFs Fast!

Number of Rooms
Bedrooms:3
Full Baths:2
Half Baths:1

Finished Square Footage
Main Level:704 Sq. Ft.
Upper Level: 782 Sq. Ft.
Total: 1486 Sq. Ft.

Unfinished Square Footage
Garage:446 Sq. Ft.

Garage
Garage Type:Attached
Garage Size:2

Foundation
  • Basement
  • Crawlspace
  • Slab

House And Ceiling Heights
First Floor Ceiling:Varies
Second Floor Ceiling:8
Maximum House Height:26' 0"

Framing Information
Roof Framing:Truss
Exterior Wall Framing:2x6

Roof Pitch
Primary:8/12
Gable:10/12

Roof Load
Live:25
Dead:15
Wind:80

INSULATION
  • Per IRC Climate Zones

Number of Rooms
Bedrooms:3
Full Baths:2
Half Baths:1
