Plan: 3485

Plan Specification
Total Square Footage: 1,270
Main Level: 865
Second Level: 405
Bedrooms: 2
Baths: 1 Half: 0
Garages: 0
Width/Depth: 36 ft / 40 ft
Foundation: Basement, Crawl Space, Slab
Pin It
© copyright by designer
First Floor Plan:
First Floor Plan
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor Plan:
Second Floor Plan
Similar plans: 3460, 3522
More plans by this designer/architect
ShareThis
Add to Favorites
Purchase Plans
PLAN DESCRIPTION A cathedral ceiling in the living and dining room provides a large open space. The galley kitchen offers all the necessities. A guest loft upstairs hosts front and rear storage closets.
10% Off All House Plans Through The End Of August !!! see details
House Plan Pricing
$800.00
$860.00
$1,000.00
$1,800.00
More details about our plan packages
Foundation Options
$0.00
$0.00
$0.00
Additional Plan Options
$55.00
$65.00
$255.00
$255.00
Best Price Guarantee, learn more
Live Chat  |  Email
Key Features
• Basement
• Covered Front Porch
• Covered Rear Porch
• Crawlspace
• Daylight Basement
• Great Room
• Laundry 1st Fl
• Loft / Balcony
• Master Bdrm Main Floor
• None
• Slab
• Suited for sloping lot
• Vaulted Ceilings
Plan Details
General House Information
2
Number of Stories:
36' 0"
Width:
40' 4"
Depth:
Single
Dwelling Number:
None
Bonus Access:
Exterior Style
Cottage
Lake
Southern
Facade
Siding
Number of Rooms
2
Bedrooms:
1
Full Baths:
Finished Square Footage
865 Sq. Ft.
Main Level:
405 Sq. Ft.
Upper Level:
1,270 Sq. Ft.
Total:
Unfinished Square Footage
588 Sq. Ft.
Porch:
GARAGE
0
Garage Size:
Foundation
Basement
Crawl Space
Slab
House And Ceiling Heights
8
First Floor Ceiling:
8
Second Floor Ceiling:
25' 0"
Maximum House Height:
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
12/12
Primary:
Roof Load
30
Live:
15
Dead:
Insulation (R)
Per IRC Climate Zones
Number of Rooms
2
Bedrooms:
1
Full Baths:
