Plan: 5827

Plan Specification
Total Square Footage: 3,020
Main Level: 1,440
Second Level: 1,440
Lower Level: 140
Bonus: 720
Bedrooms: 4
Baths: 2 Half: 1
Garages: 2
Width/Depth: 30 ft / 56 ft
Foundation: WALK OUT BASEMENT
ENERGY STAR APPROVED
Pin It
© copyright by designer
First Floor:
First Floor
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor:
Second Floor
© copyright by designer
Ground Level:
Ground Level
Similar plans: 6267, 1133, 5822, 7122
More plans by this designer/architect
ShareThis
Add to Favorites
Purchase Plans
PLAN DESCRIPTION Welcoming porches adorn this narrow drive-under plan. Never would you expect to find a 30' wide plan with a side entry garage that could fit on a 45'-50' wide lot, but when you examine the unique garage entry, you'll see how it can be done. This house is perfect for narrow lot development that has a little fall to the property. This can be built where a rear loading garage plan wouldn't work.
ZIP CODE RESTRICTED IN 30080
Get Your House Plans In Minutes!
NEW PDFs Now!™ Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
IT’S THE HOME FOR THE HOLIDAYS SALE! SAVE $50 OFF YOUR PLAN TODAY! see details
House Plan Pricing
PDFs Now!™ $900.00
$1,000.00
PDFs Now!™ $1,200.00
$1,200.00
More details about our plan packages
Foundation Options
$0.00
Additional Plan Options
$2,225.00
$60.00
$50.00
$300.00
$400.00
$300.00
$500.00
Best Price Guarantee, learn more

Live Chat  |  Email
Key Features
• Attached
• Covered Front Porch
• Deck
• Dining Room
• Drive-under
• Family Room
• Fireplace
• Formal LR
• Foyer
• Front Porch
• Home Office
• Kitchen Island
• Laundry 2nd Fl
• Library/Media Rm
• Loft / Balcony
• Master Bdrm Upstairs
• Nook / Breakfast Area
• Open Floor Plan
• Peninsula / Eating Bar
• Rec Room
• Separate Tub and Shower
• Side-entry
• Split Bedrooms
• Storage Space
• Suited for narrow lot
• Suited for sloping lot
• Unfinished Space
• Vaulted Ceilings
• Walk-in Closet
• Walk-in Pantry
• Walkout Basement
Plan Details
General House Information
2
Number of Stories:
30' 0"
Width:
56' 0"
Depth:
Single
Dwelling Number:
Exterior Style
Beach
Craftsman
Southern
Number of Rooms
4
Bedrooms:
2
Full Baths:
1
Half Baths:
Finished Square Footage
1,440 Sq. Ft.
Main Level:
1,440 Sq. Ft.
Upper Level:
140 Sq. Ft.
Lower Level:
3,020 Sq. Ft.
Total:
Unfinished Square Footage
720 Sq. Ft.
Garage:
480 Sq. Ft.
Porch:
216 Sq. Ft.
Deck:
720 Sq. Ft.
Bonus Room:
GARAGE
Side
Garage Location:
2
Garage Size:
Foundation
WALK OUT BASEMENT
House And Ceiling Heights
10
First Floor Ceiling:
9
Second Floor Ceiling:
32' 0"
Maximum House Height:
Framing Information
Truss
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
9/12
Primary:
Roof Load
20
Live:
10
Dead:
Insulation (R)
Per IRC Climate Zones
Number of Rooms
4
Bedrooms:
2
Full Baths:
1
Half Baths:
