House Plan: 3869

Plan Specification
Total Square Footage: 1,416
Main Level: 1,016
Second Level: 400
Bedrooms: 3
Baths: 2 Half: 0
Garages: 0
Width/Depth: 24 ft / 44 ft
Foundation: Basement, Crawl Space
Pin It
View typical construction drawings by this designer >
© copyright by designer
First Floor Plan:
First Floor Plan
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor Plan:
Second Floor Plan
Similar plans: 3765, 3824, 3768, 1878
More plans by this designer/architect
ShareThis
Add to Favorites
Purchase Plans
Get Your House Plans In Minutes!
NEW PDFs Now!™ Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
House Plan Pricing
PDFs Now!™ $595.00
PDFs Now!™ $795.00
$795.00
$825.00
$875.00
More details about our plan packages
Foundation Options
PDFs Now!™ available $0.00
PDFs Now!™ available $100.00
Additional Plan Options
$175.00
$50.00
$85.00
$50.00
$150.00
$250.00
Best Price Guarantee, learn more

Live Chat  |  Email
Key Features
• Deck
• Family Kitchen
• Fireplace
• Foyer
• Front Porch
• Great Room
• Laundry 1st Fl
• Loft / Balcony
• Loft / Study
• Master Bdrm Upstairs
• Master Bedroom Up
• Mud Room
• None
• Nook / Breakfast Area
• Suited for narrow lot
• Suited for view lot
• Vaulted Ceilings
• Walk-in Closet
Plan Details
General House Information
2
Number of Stories:
24' 0"
Width:
44' 4"
Depth:
Single
Dwelling Number:
Exterior Style
Beach
Contemporary
Modern
Facade
Owner's Choice
OwnersChoice
Number of Rooms
3
Bedrooms:
2
Full Baths:
Finished Square Footage
1,016 Sq. Ft.
Main Level:
400 Sq. Ft.
Upper Level:
1,416 Sq. Ft.
Total:
GARAGE
0
Garage Size:
Foundation
Basement
Crawl Space
House And Ceiling Heights
8.1
First Floor Ceiling:
8.1
Second Floor Ceiling:
29' 0"
Maximum House Height:
Framing Information
2x4
Exterior Wall Framing:
Roof Pitch
12/ 12
Primary:
24/ 12
Secondary:
Roof Load
35
Live:
Insulation (R)
13
Exterior Wall:
0
Interior Wall:
38
Ceiling:
19
Floor:
Number of Rooms
3
Bedrooms:
2
Full Baths:
