House Plan: DFD-5170

See All 31 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
9,832
BEDS
5
BATHS
7
STORIES
2
CARS
4
HOUSE PLANS SALE
START AT  $3,553.00
For questions and help, live chat, email or call us at 877-895-5299
Floor Plans
Click to Zoom In on Floor Plan

House Plan 5170
House Plan Pricing
STEP 1 Select Your Package

PDF Single Build


Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $4,180
Most recommended package

5 Printed Sets


Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets $4,380
Five printed sets of house plans

CAD Single Build


2D electronic computer files, completely editable, for design professional use, when making extensive modifications or in the event engineering is required in the area where you are building.

CAD Single Build $6,270
2D electronic editable computer files
STEP 2 Need To Reverse This Plan?
STEP 3 CHOOSE YOUR FOUNDATION
STEP 4 OPTIONAL ADD-ONS
Subtotal
$4180
FREE SHIPPING

Plan Details
See All Details
Finished Square Footage
6,515 Sq. Ft.
Main Level:
3,317 Sq. Ft.
Upper Level:
9,832 Sq. Ft.
Total:
Room Details
5
Bedrooms:
7
Full Baths:
General House Information
2
Number of Stories:
124' 0"
Width:
104' 0"
Depth:
Single
Dwelling Number:
Unfinished Square Footage
1136 Sq. Ft.
Garage:
414 Sq. Ft.
Bonus Room:
GARAGE
Side
Garage Location:
4
Garage Size:
Exterior Style
Traditional
Collections
Luxury
Old House Classics
Open Floor Plan
Foundation
Slab
Framing Information
Stick
Roof Framing:
2x6
Exterior Wall Framing:
Roof Pitch
8
Primary:
8
Secondary:
Insulation (R)
0
Exterior Wall:
0
Interior Wall:
0
Ceiling:
0
Floor:
House And Ceiling Heights
12
First Floor Ceiling:
10
Second Floor Ceiling:
36' 0"
Maximum House Height:
Key Features
2 Story Volume
Arches
Attached
Breezeway
Country Kitchen
Covered Front Porch
Covered Rear Porch
Deck
Dining Room
Exercise Room
Family Room
Fireplace
Formal LR
Foyer
Front Porch
Home Office
Kitchen Island
Laundry 1st Fl
Library/Media Rm
Master Bdrm Main Floor
Nook / Breakfast Area
Open Floor Plan
Rear Porch
Separate Tub and Shower
Side-entry
Slab
Vaulted Ceilings
