House Plan: 7020

Plan Specification
Total Entire Building: 2,364
Total Living Per Unit: 1,140
Bedrooms: 2
Baths: 1 Half: 1
Garages: 0
Width/Depth: 40 ft / 36 ft
Foundation: Concrete Slab Foundation, Optional Crawl Space Foundation, Optional Custom Foundation Design
Pin It
View typical construction drawings by this designer >
© copyright by designer
First Floor Plan:
First Floor Plan
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Second Floor Plan:
Second Floor Plan
Similar plans: 5026, 5363
More plans by this designer/architect
ShareThis
Add to Favorites
Purchase Plans
Get Your House Plans In Minutes!
NEW PDFs Now!™ Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
House Plan Pricing
PDFs Now!™ $600.00
PDFs Now!™ $750.00
$780.00
$795.00
$840.00
$920.00
$1,508.00
More details about our plan packages
Foundation Options
PDFs Now!™ available $0.00
PDFs Now!™ available $100.00
$300.00
Additional Plan Options
$175.00
$100.00
$15.00
PDFs Now!™ available $90.00
$15.00
$60.00
Best Price Guarantee, learn more

Live Chat  |  Email
Key Features
• Front Porch
• None
• Suited for narrow lot
Plan Details
General House Information
2
Number of Stories:
40' 0"
Width:
36' 0"
Depth:
Duplex
Dwelling Number:
Exterior Style
Cape Cod
Traditional
Facade
Brick/Siding
Number of Rooms
2
Bedrooms:
1
Full Baths:
1
Half Baths:
Finished Square Footage
1,140 Sq. Ft.
Total:
Unfinished Square Footage
96 Sq. Ft.
Porch:
GARAGE
0
Garage Size:
Foundation
Concrete Slab Foundation
Optional Crawl Space Foundation
Optional Custom Foundation Design
House And Ceiling Heights
8 & 10
First Floor Ceiling:
8
Second Floor Ceiling:
26' 0"
Maximum House Height:
Framing Information
Stick
Roof Framing:
2x6
Exterior Wall Framing:
Roof Pitch
7:12
Primary:
Insulation (R)
19
Exterior Wall:
0
Interior Wall:
38
Ceiling:
0
Floor:
Number of Rooms
2
Bedrooms:
1
Full Baths:
1
Half Baths:
