Plan: 7123

Plan Specification
Total Square Footage: 750
Second Level: 750
Bedrooms: 1
Baths: 1 Half: 0
Garages: 3
Width/Depth: 38 ft / 24 ft
Foundation: Slab Foundation (Please allow 2-3 Days for Delivery)
Pin It
© copyright by designer
Garage Level:
Garage Level
Need to make changes?
Call for a free modification quote
877-895-5299 or LIVE CHAT NOW
or use this quote form
© copyright by designer
Living Area Floorplan:
Living Area Floorplan
© copyright by designer
All Elevations:
All Elevations
Similar plans: 7124, 8323, 7125, 8335
More plans by this designer/architect
ShareThis
Add to Favorites
Purchase Plans
PLAN DESCRIPTION The Hudson Carriage House is a 3 car garage with a 750 sq. ft. studio above. With siding exterior reminiscent of a country barn, this plan would be perfect temporary quarters during construction of your permanent home. Or it would be ideal for an in-law apartment, nanny quarters, college student apartment, etc. This design features an eat-in kitchen, a spacious family room, a bathroom and a bedroom with a roomy closet The laundry appliances are tucked beneath the stairs on the garage level with an optional laundry chute on the living level.
Get Your House Plans In Minutes!
NEW PDFs Now!™ Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
IT’S THE HOME FOR THE HOLIDAYS SALE! SAVE $100 OFF YOUR PLAN TODAY! see details
House Plan Pricing
PDFs Now!™ $695.00
PDFs Now!™ $795.00
$845.00
$895.00
$945.00
$1,095.00
More details about our plan packages
Foundation Options
PDFs Now!™ available $0.00
Additional Plan Options
$175.00
$125.00
$35.00
$100.00
$175.00
$250.00
Best Price Guarantee, learn more

Live Chat  |  Email
Key Features
• Detached
• No Porch
• Slab
• Suited for narrow lot
Plan Details
General House Information
2
Number of Stories:
38' 0"
Width:
24' 0"
Depth:
Garage
Dwelling Number:
None
Bonus Access:
Exterior Style
Country
Southern
Traditional
Number of Rooms
1
Bedrooms:
1
Full Baths:
Finished Square Footage
750 Sq. Ft.
Upper Level:
750 Sq. Ft.
Total:
Unfinished Square Footage
858 Sq. Ft.
Garage:
GARAGE
Front
Garage Location:
3
Garage Size:
Foundation
Slab Foundation (Please allow 2-3 Days for Delivery)
House And Ceiling Heights
8'-0"
First Floor Ceiling:
9'-0"
Second Floor Ceiling:
24' 8"
Maximum House Height:
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
12/12
Primary:
12/12
Gable:
Roof Load
30 PSF
Live:
90 MPH
Wind:
Insulation (R)
21
Exterior Wall:
0
Interior Wall:
38
Ceiling:
25
Floor:
Number of Rooms
1
Bedrooms:
1
Full Baths:
